C1.5 (50 Hz) - GRUPOS GERADORES
- ColeçãoGRUPOS GERADORES
Descrição
Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.
Informações Tećnicas
- Minimum Rating: 10.0 kVA
- Maximum Rating: 13.5 kVA
- Emissions/Fuel Strategy: EU Stage IIIA
Mais informações
Generator Set Specifications
- Minimum Rating: 10.0 kVA
- Maximum Rating: 13.5 kVA
- Voltage: 110 to 415 Volts
- Frequency: 50 Hz
- Speed: 1500 rpm
- Emissions/Fuel Strategy: R96/EUIIIa Equivalent
- Length - Maximum: 1400 mm / 55.1 in
- Width - Maximum: 620 mm / 24.4 in
- Height - Maximum: 1054 mm / 41.5 in
- Duty Cycle: Standby, Prime
Generator Set Configurations
- Emissions/Fuel Strategy: EU Stage IIIA
Engine Specifications
- Engine Model: Cat® C1.5
- Displacement: 1.5 l / 91.3 in³
- Fuel System: Indirect Injection
- Governor Type: Mechanical
- Compression Ratio: 22.5:1
- Bore: 84 mm / 3.3 in
- Stroke: 90 mm / 3.5 in
- Aspiration: Naturally Aspirated
Generator Set Dimensions
- Length - Maximum: 1400 mm / 55.1 in
- Width - Maximum: 620 mm / 24.4 in
- Height - Maximum: 1054 mm / 41.5 in
Dimensions
- Length - Maximum: 1400 mm / 55.1 in
- Width - Maximum: 620 mm / 24.4 in
- Height - Maximum: 1054 mm / 41.5 in
