Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.

Informações Tećnicas

• Minimum Rating: 320 ekW
• Maximum Rating: 400 ekW
• Emissions/Fuel Strategy: EPA Stationary Emerg Use

Mais informações

Generator Set Specifications

• Minimum Rating: 320 ekW
• Maximum Rating: 400 ekW
• Emissions/Fuel Strategy: EPA Stationary Emerg Use
• Voltage: 208 to 600 Volts
• Frequency: 60 Hz
• Speed: 1800 rpm
• Duty Cycle: Standby, Prime

Engine Specifications

• Engine Model: C13 ACERT In-line 6, 4-cycle diesel
• Bore: 130 mm / 5.12 in
• Stroke: 157 mm / 6.2 in
• Displacement: 12.5 B / 763 in³
• Compression Ratio: 16.3:1
• Aspiration: Turbocharged Air to Air Aftercooled
• Fuel System: MEUI
• Governor Type: Adem™A4

Generator Set Dimensions

• Length - Maximum: 4743 mm / 186.7 in
• Height - Maximum: 2133 mm / 84 in
