Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.

Informações Tećnicas

• Minimum Rating: 550 kVA
• Maximum Rating: 715 kVA
• Emissions/Fuel Strategy: Low Fuel, EU Stage IIIA

Mais informações

Generator Set Specifications

• Minimum Rating: 550 kVA
• Maximum Rating: 715 kVA
• Emissions/Fuel Strategy: Low Fuel, EU Stage IIIA
• Voltage: 380 to 415 Volts
• Frequency: 50 Hz
• Speed: 1500 rpm
• Duty Cycle: Standby, Prime

Engine Specifications

• Engine Model: C18 ATAAC, I-6, 4-Stroke Water-Cooled Diesel
• Bore: 145 mm / 5.71 in
• Stroke: 183 mm / 7.2 in
• Displacement: 18.1 l / 1106.4 in³
• Compression Ratio: 14.5:1
• Aspiration: Air to Air Aftercooled
• Fuel System: Electronic unit injection
• Governor Type: Adem™A4

Generator Set Dimensions

• Width - Maximum: 2056 mm / 80.9 in
• Height - Maximum: 2737 mm / 107.8 in
