Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.

Informações Tećnicas

• Minimum Rating: 500 ekW
• Maximum Rating: 750 ekW
• Emissions/Fuel Strategy: U.S. EPA Certified

Mais informações

Generator Set Specifications

• Minimum Rating: 500 ekW
• Maximum Rating: 750 ekW
• Emissions/Fuel Strategy: U.S. EPA Certified
• Voltage: 208 to 600 Volts
• Frequency: 60 Hz
• Speed: 1800 rpm
• Duty Cycle: Standby, Prime

Engine Specifications

• Engine Model: Cat® C18 ATAACTM In-line 6, 4-cycle diesel
• Bore: 145 mm / 5.71 in
• Stroke: 183 mm / 7.2 in
• Displacement: 18.1 l / 1106.3 in³
• Compression Ratio: 14:01
• Aspiration: Turbocharged Air to Air Aftercooled
• Fuel System: Electronic unit injection
• Governor Type: Electronic ADEM™ A4

Generator Set Dimensions

• Length - Maximum: 3512 mm / 138 in
• Width - Maximum: 1690 mm / 67 in
• Height - Maximum: 2222 mm / 88 in
